92 Series | CVV ISO 14541 Screw-To-Connect Quick Couplings (Stainless Steel)
| Categories | Threaded Poppet Couplers |
|---|---|
| Interchange | DNP PVVX SERIES |
| Interchange | FASTER CVV SERIES |
| Interchange | VOSWINKEL HS-VA SERIES |
| Update Time | Sep 12,2025 |
Detail Information
92 Series
High Pressure Screw-To-Connect Coupling (Stainless Steel)
Poppet Valve, ISO-14541 STANDARD
This EH series is interchangeable with DNP PVVX SERIES, FASTER CVV SERIES, and VOSWINKEL HS-VA SERIES. General-purpose screw couplings designed for reliable operation under residual pressure conditions. Engineered to withstand high-pressure surges and flow impulses while maintaining ISO 14541 interchangeability.
Female
| Other Threads/Fitting Ends Are Available Upon Request | |||||
| Art. No. | Body Size (inch) | Lp(mm) | B(mm) | Hs(mm) | T |
| HFSSFC9214-1/4" | 1/4'' | 69.5 | 13 | 19 | 1/4"BSPP |
HFSSFC9238-3/8" | 3/8'' | 69.5 | 17.5 | 24 | 3/8"BSPP |
| HFSSFC9212-1/2" | 1/2'' | 71.5 | 22.1 | 30 | 1/2"BSPP |
HFSSFC9234-3/4" | 3/4'' | 85 | 28.1 | 36 | 3/4"BSPP |
HFSSFC9210-1" | 1'' | 100 | 35 | 41 | 1"BSPP |
Male
| Other Threads/Fitting Ends Are Available Upon Request | |||||
| Art. No. | Body Size (inch) | Ls(mm) | D(mm) | Hs(mm) | T |
| HFSSFP9214-1/4" | 1/4'' | 62 | 30 | S19 | 1/4"BSPP |
| HFSSFP9238-3/8" | 3/8'' | 64 | 35 | S24 | 3/8"BSPP |
HFSSFP9212-1/2" | 1/2'' | 67 | 42 | S30 | 1/2"BSPP |
HFSSFP9234-3/4" | 3/4'' | 78 | 48 | S36 | 3/4"BSPP |
HFSSFP9210-1" | 1'' | 87 | 55 | S41 | 1"BSPP |
